• This file is part of mpv.
• mpv is free software; you can redistribute it and/or
• modify it under the terms of the GNU Lesser General Public
• License as published by the Free Software Foundation; either
• version 2.1 of the License, or (at your option) any later version.
• mpv is distributed in the hope that it will be useful,
• but WITHOUT ANY WARRANTY; without even the implied warranty of
• MERCHANTABILITY or FITNESS FOR A PARTICULAR PURPOSE. See the
• GNU Lesser General Public License for more details.
• You should have received a copy of the GNU Lesser General Public
• License along with mpv. If not, see http://www.gnu.org/licenses/.
  */

#ifndef MPLAYER_CFG_MPLAYER_H
#define MPLAYER_CFG_MPLAYER_H

/*

• config for cfgparser
  */

#include
#include
#include
#include
#include

#include "config.h"

#ifdef _WIN32
#include
#endif

#include "options.h"
#include "m_config.h"
#include "m_option.h"
#include "common/common.h"
#include "stream/stream.h"
#include "video/csputils.h"
#include "video/hwdec.h"
#include "video/image_writer.h"
#include "sub/osd.h"
#include "player/core.h"
#include "player/command.h"
#include "stream/stream.h"
#include "demux/demux.h"

#if HAVE_DRM
#include "video/out/drm_common.h"
#endif

static void print_version(struct mp_log *log)
{
mp_print_version(log, true);
}

extern const struct m_sub_options tv_params_conf;
extern const struct m_sub_options stream_cdda_conf;
extern const struct m_sub_options stream_dvb_conf;
extern const struct m_sub_options stream_lavf_conf;
extern const struct m_sub_options sws_conf;
extern const struct m_sub_options zimg_conf;
extern const struct m_sub_options drm_conf;
extern const struct m_sub_options demux_rawaudio_conf;
extern const struct m_sub_options demux_rawvideo_conf;
extern const struct m_sub_options demux_lavf_conf;
extern const struct m_sub_options demux_mkv_conf;
extern const struct m_sub_options demux_cue_conf;
extern const struct m_sub_options vd_lavc_conf;
extern const struct m_sub_options ad_lavc_conf;
extern const struct m_sub_options input_config;
extern const struct m_sub_options encode_config;
extern const struct m_sub_options ra_ctx_conf;
extern const struct m_sub_options gl_video_conf;
extern const struct m_sub_options ao_alsa_conf;

extern const struct m_sub_options demux_conf;
extern const struct m_sub_options demux_cache_conf;

extern const struct m_obj_list vf_obj_list;
extern const struct m_obj_list af_obj_list;
extern const struct m_obj_list vo_obj_list;

extern const struct m_sub_options ao_conf;

extern const struct m_sub_options opengl_conf;
extern const struct m_sub_options vulkan_conf;
extern const struct m_sub_options vulkan_display_conf;
extern const struct m_sub_options spirv_conf;
extern const struct m_sub_options d3d11_conf;
extern const struct m_sub_options d3d11va_conf;
extern const struct m_sub_options angle_conf;
extern const struct m_sub_options cocoa_conf;
extern const struct m_sub_options macos_conf;
extern const struct m_sub_options wayland_conf;
extern const struct m_sub_options vaapi_conf;

static const struct m_sub_options screenshot_conf = {
.opts = image_writer_opts,
.size = sizeof(struct image_writer_opts),
.defaults = &image_writer_opts_defaults,
};

#undef OPT_BASE_STRUCT
#define OPT_BASE_STRUCT struct mp_vo_opts

static const m_option_t mp_vo_opt_list[] = {
{"vo", OPT_SETTINGSLIST(video_driver_list, &vo_obj_list)},
{"taskbar-progress", OPT_FLAG(taskbar_progress)},
{"snap-window", OPT_FLAG(snap_window)},
{"ontop", OPT_FLAG(ontop)},
{"ontop-level", OPT_CHOICE(ontop_level, {"window", -1}, {"system", -2},
{"desktop", -3}), M_RANGE(0, INT_MAX)},
{"border", OPT_FLAG(border)},
{"fit-border", OPT_FLAG(fit_border),
.deprecation_message = "the option is ignored and no longer needed"},
{"on-all-workspaces", OPT_FLAG(all_workspaces)},
{"geometry", OPT_GEOMETRY(geometry)},
{"autofit", OPT_SIZE_BOX(autofit)},
{"autofit-larger", OPT_SIZE_BOX(autofit_larger)},
{"autofit-smaller", OPT_SIZE_BOX(autofit_smaller)},
{"window-scale", OPT_DOUBLE(window_scale), M_RANGE(0.001, 100)},
{"window-minimized", OPT_FLAG(window_minimized)},
{"window-maximized", OPT_FLAG(window_maximized)},
{"focus-on-open", OPT_BOOL(focus_on_open)},
{"force-window-position", OPT_FLAG(force_window_position)},
{"x11-name", OPT_STRING(winname)},
{"wayland-app-id", OPT_STRING(appid)},
{"monitoraspect", OPT_FLOAT(force_monitor_aspect), M_RANGE(0.0, 9.0)},
{"monitorpixelaspect", OPT_FLOAT(monitor_pixel_aspect),
M_RANGE(1.0/32.0, 32.0)},
{"fullscreen", OPT_BOOL(fullscreen)},
{"fs", OPT_ALIAS("fullscreen")},
{"native-keyrepeat", OPT_FLAG(native_keyrepeat)},
{"panscan", OPT_FLOAT(panscan), M_RANGE(0.0, 1.0)},
{"video-zoom", OPT_FLOAT(zoom), M_RANGE(-20.0, 20.0)},
{"video-pan-x", OPT_FLOAT(pan_x), M_RANGE(-3.0, 3.0)},
{"video-pan-y", OPT_FLOAT(pan_y), M_RANGE(-3.0, 3.0)},
{"video-align-x", OPT_FLOAT(align_x), M_RANGE(-1.0, 1.0)},
{"video-align-y", OPT_FLOAT(align_y), M_RANGE(-1.0, 1.0)},
{"video-scale-x", OPT_FLOAT(scale_x), M_RANGE(0, 10000.0)},
{"video-scale-y", OPT_FLOAT(scale_y), M_RANGE(0, 10000.0)},
{"video-margin-ratio-left", OPT_FLOAT(margin_x[0]), M_RANGE(0.0, 1.0)},
{"video-margin-ratio-right", OPT_FLOAT(margin_x[1]), M_RANGE(0.0, 1.0)},
{"video-margin-ratio-top", OPT_FLOAT(margin_y[0]), M_RANGE(0.0, 1.0)},
{"video-margin-ratio-bottom", OPT_FLOAT(margin_y[1]), M_RANGE(0.0, 1.0)},
{"video-unscaled", OPT_CHOICE(unscaled,
{"no", 0}, {"yes", 1}, {"downscale-big", 2})},
{"wid", OPT_INT64(WinID)},
{"screen", OPT_CHOICE(screen_id, {"default", -1}), M_RANGE(0, 32)},
{"screen-name", OPT_STRING(screen_name)},
{"fs-screen", OPT_CHOICE(fsscreen_id, {"all", -2}, {"current", -1}),
M_RANGE(0, 32)},
{"fs-screen-name", OPT_STRING(fsscreen_name)},
{"keepaspect", OPT_FLAG(keepaspect)},
{"keepaspect-window", OPT_FLAG(keepaspect_window)},
{"hidpi-window-scale", OPT_FLAG(hidpi_window_scale)},
{"native-fs", OPT_FLAG(native_fs)},
{"override-display-fps", OPT_DOUBLE(override_display_fps),
M_RANGE(0, DBL_MAX)},
{"video-timing-offset", OPT_DOUBLE(timing_offset), M_RANGE(0.0, 1.0)},
#if HAVE_X11
{"x11-netwm", OPT_CHOICE(x11_netwm, {"auto", 0}, {"no", -1}, {"yes", 1})},
{"x11-bypass-compositor", OPT_CHOICE(x11_bypass_compositor,
{"no", 0}, {"yes", 1}, {"fs-only", 2}, {"never", 3})},
#endif
#if HAVE_WIN32_DESKTOP
{"vo-mmcss-profile", OPT_STRING(mmcss_profile)},
#endif
#if HAVE_DRM
{"", OPT_SUBSTRUCT(drm_opts, drm_conf)},
#endif
#if HAVE_EGL_ANDROID
{"android-surface-size", OPT_SIZE_BOX(android_surface_size)},
#endif
{"swapchain-depth", OPT_INT(swapchain_depth), M_RANGE(1, 8)},
{0}
};

const struct m_sub_options vo_sub_opts = {
.opts = mp_vo_opt_list,
.size = sizeof(struct mp_vo_opts),
.defaults = &(const struct mp_vo_opts){
.video_driver_list = NULL,
.monitor_pixel_aspect = 1.0,
.screen_id = -1,
.fsscreen_id = -1,
.panscan = 0.0f,
.scale_x = 1.0f,
.scale_y = 1.0f,
.keepaspect = 1,
.keepaspect_window = 1,
.hidpi_window_scale = 1,
.native_fs = 1,
.taskbar_progress = 1,
.snap_window = 0,
.border = 1,
.fit_border = 1,
.appid = "mpv",
.WinID = -1,
.window_scale = 1.0,
.x11_bypass_compositor = 2,
.mmcss_profile = "Playback",
.ontop_level = -1,
.timing_offset = 0.050,
.swapchain_depth = 3,
.focus_on_open = true,
},
};

#undef OPT_BASE_STRUCT
#define OPT_BASE_STRUCT struct mp_sub_filter_opts

const struct m_sub_options mp_sub_filter_opts = {
.opts = (const struct m_option[]){
{"sub-filter-sdh", OPT_FLAG(sub_filter_SDH)},
{"sub-filter-sdh-harder", OPT_FLAG(sub_filter_SDH_harder)},
{"sub-filter-regex-enable", OPT_FLAG(rf_enable)},
{"sub-filter-regex-plain", OPT_FLAG(rf_plain)},
{"sub-filter-regex", OPT_STRINGLIST(rf_items)},
{"sub-filter-jsre", OPT_STRINGLIST(jsre_items)},
{"sub-filter-regex-warn", OPT_FLAG(rf_warn)},
{0}
},
.size = sizeof(OPT_BASE_STRUCT),
.defaults = &(OPT_BASE_STRUCT){
.rf_enable = 1,
},
.change_flags = UPDATE_SUB_FILT,
};

#undef OPT_BASE_STRUCT
#define OPT_BASE_STRUCT struct mp_subtitle_opts

const struct m_sub_options mp_subtitle_sub_opts = {
.opts = (const struct m_option[]){
{"sub-delay", OPT_FLOAT(sub_delay)},
{"sub-fps", OPT_FLOAT(sub_fps)},
{"sub-speed", OPT_FLOAT(sub_speed)},
{"sub-visibility", OPT_FLAG(sub_visibility)},
{"secondary-sub-visibility", OPT_FLAG(sec_sub_visibility)},
{"sub-forced-only", OPT_CHOICE(forced_subs_only,
{"auto", -1}, {"no", 0}, {"yes", 1})},
{"stretch-dvd-subs", OPT_FLAG(stretch_dvd_subs)},
{"stretch-image-subs-to-screen", OPT_FLAG(stretch_image_subs)},
{"image-subs-video-resolution", OPT_FLAG(image_subs_video_res)},
{"sub-fix-timing", OPT_FLAG(sub_fix_timing)},
{"sub-pos", OPT_INT(sub_pos), M_RANGE(0, 150)},
{"sub-gauss", OPT_FLOAT(sub_gauss), M_RANGE(0.0, 3.0)},
{"sub-gray", OPT_FLAG(sub_gray)},
{"sub-ass", OPT_FLAG(ass_enabled), .flags = UPDATE_SUB_HARD},
{"sub-scale", OPT_FLOAT(sub_scale), M_RANGE(0, 100)},
{"sub-ass-line-spacing", OPT_FLOAT(ass_line_spacing),
M_RANGE(-1000, 1000)},
{"sub-use-margins", OPT_FLAG(sub_use_margins)},
{"sub-ass-force-margins", OPT_FLAG(ass_use_margins)},
{"sub-ass-vsfilter-aspect-compat", OPT_FLAG(ass_vsfilter_aspect_compat)},
{"sub-ass-vsfilter-color-compat", OPT_CHOICE(ass_vsfilter_color_compat,
{"no", 0}, {"basic", 1}, {"full", 2}, {"force-601", 3})},
{"sub-ass-vsfilter-blur-compat", OPT_FLAG(ass_vsfilter_blur_compat)},
{"embeddedfonts", OPT_FLAG(use_embedded_fonts), .flags = UPDATE_SUB_HARD},
{"sub-ass-force-style", OPT_STRINGLIST(ass_force_style_list),
.flags = UPDATE_SUB_HARD},
{"sub-ass-styles", OPT_STRING(ass_styles_file),
.flags = M_OPT_FILE | UPDATE_SUB_HARD},
{"sub-ass-hinting", OPT_CHOICE(ass_hinting,
{"none", 0}, {"light", 1}, {"normal", 2}, {"native", 3})},
{"sub-ass-shaper", OPT_CHOICE(ass_shaper,
{"simple", 0}, {"complex", 1})},
{"sub-ass-justify", OPT_FLAG(ass_justify)},
{"sub-ass-override", OPT_CHOICE(ass_style_override,
{"no", 0}, {"yes", 1}, {"force", 3}, {"scale", 4}, {"strip", 5})},
{"sub-scale-by-window", OPT_FLAG(sub_scale_by_window)},
{"sub-scale-with-window", OPT_FLAG(sub_scale_with_window)},
{"sub-ass-scale-with-window", OPT_FLAG(ass_scale_with_window)},
{"sub", OPT_SUBSTRUCT(sub_style, sub_style_conf)},
{"sub-clear-on-seek", OPT_FLAG(sub_clear_on_seek)},
{"teletext-page", OPT_INT(teletext_page), M_RANGE(1, 999)},
{"sub-past-video-end", OPT_FLAG(sub_past_video_end)},
{0}
},
.size = sizeof(OPT_BASE_STRUCT),
.defaults = &(OPT_BASE_STRUCT){
.sub_visibility = 1,
.sec_sub_visibility = 1,
.forced_subs_only = -1,
.sub_pos = 100,
.sub_speed = 1.0,
.ass_enabled = 1,
.sub_scale_by_window = 1,
.ass_use_margins = 0,
.sub_use_margins = 1,
.ass_scale_with_window = 0,
.sub_scale_with_window = 1,
.teletext_page = 100,
.sub_scale = 1,
.ass_vsfilter_aspect_compat = 1,
.ass_vsfilter_color_compat = 1,
.ass_vsfilter_blur_compat = 1,
.ass_style_override = 1,
.ass_shaper = 1,
.use_embedded_fonts = 1,
},
.change_flags = UPDATE_OSD,
};

#undef OPT_BASE_STRUCT
#define OPT_BASE_STRUCT struct mp_osd_render_opts

const struct m_sub_options mp_osd_render_sub_opts = {
.opts = (const struct m_option[]){
{"osd-bar-align-x", OPT_FLOAT(osd_bar_align_x), M_RANGE(-1.0, +1.0)},
{"osd-bar-align-y", OPT_FLOAT(osd_bar_align_y), M_RANGE(-1.0, +1.0)},
{"osd-bar-w", OPT_FLOAT(osd_bar_w), M_RANGE(1, 100)},
{"osd-bar-h", OPT_FLOAT(osd_bar_h), M_RANGE(0.1, 50)},
{"osd", OPT_SUBSTRUCT(osd_style, osd_style_conf)},
{"osd-scale", OPT_FLOAT(osd_scale), M_RANGE(0, 100)},
{"osd-scale-by-window", OPT_FLAG(osd_scale_by_window)},
{"force-rgba-osd-rendering", OPT_FLAG(force_rgba_osd)},
{0}
},
.size = sizeof(OPT_BASE_STRUCT),
.defaults = &(OPT_BASE_STRUCT){
.osd_bar_align_y = 0.5,
.osd_bar_w = 75.0,
.osd_bar_h = 3.125,
.osd_scale = 1,
.osd_scale_by_window = 1,
},
.change_flags = UPDATE_OSD,
};

#undef OPT_BASE_STRUCT
#define OPT_BASE_STRUCT struct dvd_opts

const struct m_sub_options dvd_conf = {
.opts = (const struct m_option[]){
{"dvd-device", OPT_STRING(device), .flags = M_OPT_FILE},
{"dvd-speed", OPT_INT(speed)},
{"dvd-angle", OPT_INT(angle), M_RANGE(1, 99)},
{0}
},
.size = sizeof(struct dvd_opts),
.defaults = &(const struct dvd_opts){
.angle = 1,
},
};

#undef OPT_BASE_STRUCT
#define OPT_BASE_STRUCT struct filter_opts

const struct m_sub_options filter_conf = {
.opts = (const struct m_option[]){
{"deinterlace", OPT_FLAG(deinterlace)},
{0}
},
.size = sizeof(OPT_BASE_STRUCT),
.change_flags = UPDATE_IMGPAR,
};

#undef OPT_BASE_STRUCT
#define OPT_BASE_STRUCT struct MPOpts

static const m_option_t mp_opts[] = {
// handled in command line pre-parser (parse_commandline.c)
{"v", &m_option_type_dummy_flag, CONF_NOCFG | M_OPT_NOPROP,
.offset = -1},
{"playlist", CONF_TYPE_STRING, CONF_NOCFG | M_OPT_FILE, .offset = -1},
{"{", &m_option_type_dummy_flag, CONF_NOCFG | M_OPT_NOPROP,
.offset = -1},
{"}", &m_option_type_dummy_flag, CONF_NOCFG | M_OPT_NOPROP,
.offset = -1},

// handled in m_config.c
{ "include", CONF_TYPE_STRING, M_OPT_FILE, .offset = -1},
{ "profile", CONF_TYPE_STRING_LIST, 0, .offset = -1},
{ "show-profile", CONF_TYPE_STRING, CONF_NOCFG | M_OPT_NOPROP |
    M_OPT_OPTIONAL_PARAM,  .offset = -1},
{ "list-options", &m_option_type_dummy_flag, CONF_NOCFG | M_OPT_NOPROP,
    .offset = -1},
{"list-properties", OPT_FLAG(property_print_help),
 .flags = CONF_NOCFG | M_OPT_NOPROP},
{ "help", CONF_TYPE_STRING, CONF_NOCFG | M_OPT_NOPROP | M_OPT_OPTIONAL_PARAM,
    .offset = -1},
{ "h", CONF_TYPE_STRING, CONF_NOCFG | M_OPT_NOPROP | M_OPT_OPTIONAL_PARAM,
    .offset = -1},

{"list-protocols", OPT_PRINT(stream_print_proto_list)},
{"version", OPT_PRINT(print_version)},
{"V", OPT_PRINT(print_version)},

#if HAVE_TESTS
{"unittest", OPT_STRING(test_mode), .flags = CONF_NOCFG | M_OPT_NOPROP},
#endif

{"player-operation-mode", OPT_CHOICE(operation_mode,
    {"cplayer", 0}, {"pseudo-gui", 1}),
    .flags = M_OPT_PRE_PARSE | M_OPT_NOPROP},

{"shuffle", OPT_FLAG(shuffle)},

// ------------------------- common options --------------------
{"quiet", OPT_FLAG(quiet)},
{"really-quiet", OPT_FLAG(msg_really_quiet),
.flags = CONF_PRE_PARSE | UPDATE_TERM},
{"terminal", OPT_FLAG(use_terminal), .flags = CONF_PRE_PARSE | UPDATE_TERM},
{"msg-level", OPT_MSGLEVELS(msg_levels),
.flags = CONF_PRE_PARSE | UPDATE_TERM},
{"dump-stats", OPT_STRING(dump_stats),
.flags = UPDATE_TERM | CONF_PRE_PARSE | M_OPT_FILE},
{"msg-color", OPT_FLAG(msg_color), .flags = CONF_PRE_PARSE | UPDATE_TERM},
{"log-file", OPT_STRING(log_file),
.flags = CONF_PRE_PARSE | M_OPT_FILE | UPDATE_TERM},
{"msg-module", OPT_FLAG(msg_module), .flags = UPDATE_TERM},
{"msg-time", OPT_FLAG(msg_time), .flags = UPDATE_TERM},
#if HAVE_WIN32_DESKTOP
{"priority", OPT_CHOICE(w32_priority,
{"no", 0},
{"realtime", REALTIME_PRIORITY_CLASS},
{"high", HIGH_PRIORITY_CLASS},
{"abovenormal", ABOVE_NORMAL_PRIORITY_CLASS},
{"normal", NORMAL_PRIORITY_CLASS},
{"belownormal", BELOW_NORMAL_PRIORITY_CLASS},
{"idle", IDLE_PRIORITY_CLASS}),
.flags = UPDATE_PRIORITY},
#endif
{"config", OPT_FLAG(load_config), .flags = CONF_PRE_PARSE},
{"config-dir", OPT_STRING(force_configdir),
.flags = CONF_NOCFG | CONF_PRE_PARSE | M_OPT_FILE},
{"reset-on-next-file", OPT_STRINGLIST(reset_options)},

#if HAVE_LUA || HAV*
{"scripts", OPT_PATHLIST(script_files), .flags = M_OPT_FILE},
{"script", OPT_CLI_ALIAS("scripts-append")},
{"script-opts", OPT_KEYVALUELIST(script_opts)},
{"load-scripts", OPT_FLAG(auto_load_scripts)},
#endif
#if HAVE_LUA
{"osc", OPT_FLAG(lua_load_osc), .flags = UPDATE_BUILTIN_SCRIPTS},
{"ytdl", OPT_FLAG(lua_load_ytdl), .flags = UPDATE_BUILTIN_SCRIPTS},
{"ytdl-format", OPT_STRING(lua_ytdl_format)},
{"ytdl-raw-options", OPT_KEYVALUELIST(lua_ytdl_raw_options)},
{"load-stats-overlay", OPT_FLAG(lua_load_stats),
.flags = UPDATE_BUILTIN_SCRIPTS},
{"load-osd-console", OPT_FLAG(lua_load_console),
.flags = UPDATE_BUILTIN_SCRIPTS},
{"load-auto-profiles",
OPT_CHOICE(lua_load_auto_profiles, {"no", 0}, {"yes", 1}, {"auto", -1}),
.flags = UPDATE_BUILTIN_SCRIPTS},
#endif

// ------------------------- stream options --------------------

#if HAVE_DVDNAV
{"", OPT_SUBSTRUCT(dvd_opts, dvd_conf)},
#endif
{"edition", OPT_CHOICE(edition_id, {"auto", -1}), M_RANGE(0, 8190)},
#if HAVE_LIBBLURAY
{"bluray-device", OPT_STRING(bluray_device), .flags = M_OPT_FILE},
#endif /* HAVE_LIBBLURAY */

// ------------------------- demuxer options --------------------

{"frames", OPT_CHOICE(play_frames, {"all", -1}), M_RANGE(0, INT_MAX)},

{"start", OPT_REL_TIME(play_start)},
{"end", OPT_REL_TIME(play_end)},
{"length", OPT_REL_TIME(play_length)},

{"play-dir", OPT_CHOICE(play_dir,
    {"forward", 1}, {"+", 1}, {"backward", -1}, {"-", -1})},

{"rebase-start-time", OPT_FLAG(rebase_start_time)},

{"ab-loop-a", OPT_TIME(ab_loop[0]), .flags = M_OPT_ALLOW_NO},
{"ab-loop-b", OPT_TIME(ab_loop[1]), .flags = M_OPT_ALLOW_NO},
{"ab-loop-count", OPT_CHOICE(ab_loop_count, {"inf", -1}),
    M_RANGE(0, INT_MAX)},

{"playlist-start", OPT_CHOICE(playlist_pos, {"auto", -1}, {"no", -1}),
    M_RANGE(0, INT_MAX)},

{"pause", OPT_FLAG(pause)},
{"keep-open", OPT_CHOICE(keep_open,
    {"no", 0},
    {"yes", 1},
    {"always", 2})},
{"keep-open-pause", OPT_FLAG(keep_open_pause)},
{"image-display-duration", OPT_DOUBLE(image_display_duration),
    M_RANGE(0, INFINITY)},

 {"index", OPT_CHOICE(index_mode, {"default", 1}, {"recreate", 0})},

// select audio/video/subtitle stream
// keep in sync with num_ptracks[] and MAX_PTRACKS
{"aid", OPT_TRACKCHOICE(stream_id[0][STREAM_AUDIO])},
{"vid", OPT_TRACKCHOICE(stream_id[0][STREAM_VIDEO])},
{"sid", OPT_TRACKCHOICE(stream_id[0][STREAM_SUB])},
{"secondary-sid", OPT_TRACKCHOICE(stream_id[1][STREAM_SUB])},
{"sub", OPT_ALIAS("sid")},
{"video", OPT_ALIAS("vid")},
{"audio", OPT_ALIAS("aid")},
{"alang", OPT_STRINGLIST(stream_lang[STREAM_AUDIO])},
{"slang", OPT_STRINGLIST(stream_lang[STREAM_SUB])},
{"vlang", OPT_STRINGLIST(stream_lang[STREAM_VIDEO])},
{"track-auto-selection", OPT_FLAG(stream_auto_sel)},
{"subs-with-matching-audio", OPT_FLAG(subs_with_matching_audio)},

{"lavfi-complex", OPT_STRING(lavfi_complex), .flags = UPDATE_LAVFI_COMPLEX},

{"audio-display", OPT_CHOICE(audio_display, {"no", 0},
    {"embedded-first", 1}, {"external-first", 2})},

{"hls-bitrate", OPT_CHOICE(hls_bitrate,
    {"no", -1}, {"min", 0}, {"max", INT_MAX}), M_RANGE(0, INT_MAX)},

{"display-tags", OPT_STRINGLIST(display_tags)},

#if HAVE_CDDA
{"cdda", OPT_SUBSTRUCT(stream_cdda_opts, stream_cdda_conf)},
{"cdrom-device", OPT_STRING(cdrom_device), .flags = M_OPT_FILE},
#endif

// demuxer.c - select audio/sub file/demuxer
{"demuxer", OPT_STRING(demuxer_name), .help = demuxer_help},
{"audio-demuxer", OPT_STRING(audio_demuxer_name), .help = demuxer_help},
{"sub-demuxer", OPT_STRING(sub_demuxer_name), .help = demuxer_help},
{"demuxer-thread", OPT_FLAG(demuxer_thread)},
{"demuxer-termination-timeout", OPT_DOUBLE(demux_termination_timeout)},
{"demuxer-cache-wait", OPT_FLAG(demuxer_cache_wait)},
{"prefetch-playlist", OPT_FLAG(prefetch_open)},
{"cache-pause", OPT_FLAG(cache_pause)},
{"cache-pause-initial", OPT_FLAG(cache_pause_initial)},
{"cache-pause-wait", OPT_FLOAT(cache_pause_wait), M_RANGE(0, DBL_MAX)},

{"mf-fps", OPT_DOUBLE(mf_fps)},
{"mf-type", OPT_STRING(mf_type)},

#if HAVE_DVBIN
{"dvbin", OPT_SUBSTRUCT(stream_dvb_opts, stream_dvb_conf)},
#endif
{"", OPT_SUBSTRUCT(stream_lavf_opts, stream_lavf_conf)},

// ------------------------- a-v sync options --------------------

// set A-V sync correction speed (0=disables it):
{"mc", OPT_FLOAT(default_max_pts_correction), M_RANGE(0, 100)},

{"audio-samplerate", OPT_INT(force_srate), .flags = UPDATE_AUDIO,
    M_RANGE(0, 16*48000)},
{"audio-channels", OPT_CHANNELS(audio_output_channels), .flags = UPDATE_AUDIO},
{"audio-format", OPT_AUDIOFORMAT(audio_output_format), .flags = UPDATE_AUDIO},
{"speed", OPT_DOUBLE(playback_speed), M_RANGE(0.01, 100.0)},

{"audio-pitch-correction", OPT_FLAG(pitch_correction)},

// set a-v distance
{"audio-delay", OPT_FLOAT(audio_delay)},

// ------------------------- codec/vfilter options --------------------

{"af-defaults", OPT_SETTINGSLIST(af_defs, &af_obj_list),
    .deprecation_message = "use --af + enable/disable flags"},
{"af", OPT_SETTINGSLIST(af_settings, &af_obj_list)},
{"vf-defaults", OPT_SETTINGSLIST(vf_defs, &vf_obj_list),
    .deprecation_message = "use --vf + enable/disable flags"},
{"vf", OPT_SETTINGSLIST(vf_settings, &vf_obj_list)},

{"", OPT_SUBSTRUCT(filter_opts, filter_conf)},

{"", OPT_SUBSTRUCT(dec_wrapper, dec_wrapper_conf)},
{"", OPT_SUBSTRUCT(vd_lavc_params, vd_lavc_conf)},
{"ad-lavc", OPT_SUBSTRUCT(ad_lavc_params, ad_lavc_conf)},

{"", OPT_SUBSTRUCT(demux_lavf, demux_lavf_conf)},
{"demuxer-rawaudio", OPT_SUBSTRUCT(demux_rawaudio, demux_rawaudio_conf)},
{"demuxer-rawvideo", OPT_SUBSTRUCT(demux_rawvideo, demux_rawvideo_conf)},
{"demuxer-mkv", OPT_SUBSTRUCT(demux_mkv, demux_mkv_conf)},
{"demuxer-cue", OPT_SUBSTRUCT(demux_cue, demux_cue_conf)},

// ------------------------- subtitles options --------------------

{"sub-files", OPT_PATHLIST(sub_name), .flags = M_OPT_FILE},
{"sub-file", OPT_CLI_ALIAS("sub-files-append")},
{"audio-files", OPT_PATHLIST(audio_files), .flags = M_OPT_FILE},
{"audio-file", OPT_CLI_ALIAS("audio-files-append")},
{"cover-art-files", OPT_PATHLIST(coverart_files), .flags = M_OPT_FILE},
{"cover-art-file", OPT_CLI_ALIAS("cover-art-files-append")},

{"sub-file-paths", OPT_PATHLIST(sub_paths), .flags = M_OPT_FILE},
{"audio-file-paths", OPT_PATHLIST(audiofile_paths), .flags = M_OPT_FILE},

{"external-files", OPT_PATHLIST(external_files), .flags = M_OPT_FILE},
{"external-file", OPT_CLI_ALIAS("external-files-append")},
{"autoload-files", OPT_FLAG(autoload_files)},

{"sub-auto", OPT_CHOICE(sub_auto,
    {"no", -1}, {"exact", 0}, {"fuzzy", 1}, {"all", 2})},
{"audio-file-auto", OPT_CHOICE(audiofile_auto,
    {"no", -1}, {"exact", 0}, {"fuzzy", 1}, {"all", 2})},
{"cover-art-auto", OPT_CHOICE(coverart_auto,
    {"no", -1}, {"exact", 0}, {"fuzzy", 1}, {"all", 2})},

{"", OPT_SUBSTRUCT(subs_rend, mp_subtitle_sub_opts)},
{"", OPT_SUBSTRUCT(subs_filt, mp_sub_filter_opts)},
{"", OPT_SUBSTRUCT(osd_rend, mp_osd_render_sub_opts)},

{"osd-bar", OPT_FLAG(osd_bar_visible), .flags = UPDATE_OSD},

//---------------------- libao/libvo options ------------------------
{"", OPT_SUBSTRUCT(ao_opts, ao_conf)},
{"audio-exclusive", OPT_FLAG(audio_exclusive), .flags = UPDATE_AUDIO},
{"audio-fallback-to-null", OPT_FLAG(ao_null_fallback)},
{"audio-stream-silence", OPT_FLAG(audio_stream_silence)},
{"audio-wait-open", OPT_FLOAT(audio_wait_open), M_RANGE(0, 60)},
{"force-window", OPT_CHOICE(force_vo,
{"no", 0}, {"yes", 1}, {"immediate", 2})},

{"volume-max", OPT_FLOAT(softvol_max), M_RANGE(100, 1000)},
// values <0 for volume and mute are legacy and ignored
{"volume", OPT_FLOAT(softvol_volume), .flags = UPDATE_VOL,
    M_RANGE(-1, 1000)},
{"mute", OPT_CHOICE(softvol_mute,
    {"no", 0},
    {"auto", 0},
    {"yes", 1}),
    .flags = UPDATE_VOL},
{"replaygain", OPT_CHOICE(rgain_mode,
    {"no", 0},
    {"track", 1},
    {"album", 2}),
    .flags = UPDATE_VOL},
{"replaygain-preamp", OPT_FLOAT(rgain_preamp), .flags = UPDATE_VOL,
    M_RANGE(-150, 150)},
{"replaygain-clip", OPT_FLAG(rgain_clip), .flags = UPDATE_VOL},
{"replaygain-fallback", OPT_FLOAT(rgain_fallback), .flags = UPDATE_VOL,
    M_RANGE(-200, 60)},
{"gapless-audio", OPT_CHOICE(gapless_audio,
    {"no", 0},
    {"yes", 1},
    {"weak", -1})},

{"title", OPT_STRING(wintitle)},
{"force-media-title", OPT_STRING(media_title)},

{"cursor-autohide", OPT_CHOICE(cursor_autohide_delay,
    {"no", -1}, {"always", -2}), M_RANGE(0, 30000)},
{"cursor-autohide-fs-only", OPT_FLAG(cursor_autohide_fs)},
{"stop-screensaver", OPT_CHOICE(stop_screensaver,
    {"no", 0},
    {"yes", 1},
    {"always", 2}),
    .flags = UPDATE_SCREENSAVER},

{"", OPT_SUBSTRUCT(video_equalizer, mp_csp_equalizer_conf)},

{"use-filedir-conf", OPT_FLAG(use_filedir_conf)},
{"osd-level", OPT_CHOICE(osd_level,
    {"0", 0}, {"1", 1}, {"2", 2}, {"3", 3})},
{"osd-on-seek", OPT_CHOICE(osd_on_seek,
    {"no", 0},
    {"bar", 1},
    {"msg", 2},
    {"msg-bar", 3})},
{"osd-duration", OPT_INT(osd_duration), M_RANGE(0, 3600000)},
{"osd-fractions", OPT_FLAG(osd_fractions)},

{"sstep", OPT_DOUBLE(step_sec), M_RANGE(0, DBL_MAX)},

{"framedrop", OPT_CHOICE(frame_dropping,
    {"no", 0},
    {"vo", 1},
    {"decoder", 2},
    {"decoder+vo", 3})},
{"video-latency-hacks", OPT_FLAG(video_latency_hacks)},

{"untimed", OPT_FLAG(untimed)},

{"stream-dump", OPT_STRING(stream_dump), .flags = M_OPT_FILE},

{"stop-playback-on-init-failure", OPT_FLAG(stop_playback_on_init_failure)},

{"loop-playlist", OPT_CHOICE(loop_times,
    {"no", 1},
    {"inf", -1}, {"yes", -1},
    {"force", -2}),
    M_RANGE(1, 10000)},
{"loop-file", OPT_CHOICE(loop_file,
    {"no", 0},
    {"inf", -1},
    {"yes", -1}),
    M_RANGE(0, 10000)},
{"loop", OPT_ALIAS("loop-file")},

{"resume-playback", OPT_FLAG(position_resume)},
{"resume-playback-check-mtime", OPT_FLAG(position_check_mtime)},
{"save-position-on-quit", OPT_FLAG(position_save_on_quit)},
{"write-filename-in-watch-later-config",
    OPT_FLAG(write_filename_in_watch_later_config)},
{"ignore-path-in-watch-later-config",
    OPT_FLAG(ignore_path_in_watch_later_config)},
{"watch-later-directory", OPT_STRING(watch_later_directory),
    .flags = M_OPT_FILE},
{"watch-later-options", OPT_STRINGLIST(watch_later_options)},

{"ordered-chapters", OPT_FLAG(ordered_chapters)},
{"ordered-chapters-files", OPT_STRING(ordered_chapters_files),
    .flags = M_OPT_FILE},
{"chapter-merge-threshold", OPT_INT(chapter_merge_threshold),
    M_RANGE(0, 10000)},

{"chapter-seek-threshold", OPT_DOUBLE(chapter_seek_threshold)},

{"chapters-file", OPT_STRING(chapter_file), .flags = M_OPT_FILE},

{"merge-files", OPT_FLAG(merge_files)},

// a-v sync stuff:
{"initial-audio-sync", OPT_FLAG(initial_audio_sync)},
{"video-sync", OPT_CHOICE(video_sync,
    {"audio", VS_DEFAULT},
    {"display-resample", VS_DISP_RESAMPLE},
    {"display-resample-vdrop", VS_DISP_RESAMPLE_VDROP},
    {"display-resample-desync", VS_DISP_RESAMPLE_NONE},
    {"display-adrop", VS_DISP_ADROP},
    {"display-vdrop", VS_DISP_VDROP},
    {"display-desync", VS_DISP_NONE},
    {"desync", VS_NONE})},
{"video-sync-max-video-change", OPT_DOUBLE(sync_max_video_change),
    M_RANGE(0, DBL_MAX)},
{"video-sync-max-audio-change", OPT_DOUBLE(sync_max_audio_change),
    M_RANGE(0, 1)},
{"video-sync-max-factor", OPT_INT(sync_max_factor), M_RANGE(1, 10)},
{"hr-seek", OPT_CHOICE(hr_seek,
    {"no", -1}, {"absolute", 0}, {"yes", 1}, {"always", 1}, {"default", 2})},
{"hr-seek-demuxer-offset", OPT_FLOAT(hr_seek_demuxer_offset)},
{"hr-seek-framedrop", OPT_FLAG(hr_seek_framedrop)},
{"autosync", OPT_CHOICE(autosync, {"no", -1}), M_RANGE(0, 10000)},

{"term-osd", OPT_CHOICE(term_osd,
    {"force", 1}, {"auto", 2}, {"no", 0}), .flags = UPDATE_OSD},

{"term-osd-bar", OPT_FLAG(term_osd_bar), .flags = UPDATE_OSD},
{"term-osd-bar-chars", OPT_STRING(term_osd_bar_chars), .flags = UPDATE_OSD},
{"term-title", OPT_STRING(term_title), .flags = UPDATE_OSD},

{"term-playing-msg", OPT_STRING(playing_msg)},
{"osd-playing-msg", OPT_STRING(osd_playing_msg)},
{"term-status-msg", OPT_STRING(status_msg), .flags = UPDATE_OSD},
{"osd-status-msg", OPT_STRING(osd_status_msg), .flags = UPDATE_OSD},
{"osd-msg1", OPT_STRING(osd_msg[0]), .flags = UPDATE_OSD},
{"osd-msg2", OPT_STRING(osd_msg[1]), .flags = UPDATE_OSD},
{"osd-msg3", OPT_STRING(osd_msg[2]), .flags = UPDATE_OSD},

{"video-osd", OPT_FLAG(video_osd), .flags = UPDATE_OSD},

{"idle", OPT_CHOICE(player_idle_mode,
    {"no",   0}, {"once", 1}, {"yes",  2})},

{"input-terminal", OPT_FLAG(consolecontrols), .flags = UPDATE_TERM},

{"input-ipc-server", OPT_STRING(ipc_path), .flags = M_OPT_FILE},

#if HAVE_POSIX
{"input-ipc-client", OPT_STRING(ipc_client)},
#endif

{"screenshot", OPT_SUBSTRUCT(screenshot_image_opts, screenshot_conf)},
{"screenshot-template", OPT_STRING(screenshot_template)},
{"screenshot-directory", OPT_STRING(screenshot_directory),
    .flags = M_OPT_FILE},
{"screenshot-sw", OPT_BOOL(screenshot_sw)},

{"record-file", OPT_STRING(record_file), .flags = M_OPT_FILE,
    .deprecation_message = "use --stream-record or the dump-cache command"},

{"", OPT_SUBSTRUCT(resample_opts, resample_conf)},

{"", OPT_SUBSTRUCT(input_opts, input_config)},

{"", OPT_SUBSTRUCT(vo, vo_sub_opts)},
{"", OPT_SUBSTRUCT(demux_opts, demux_conf)},
{"", OPT_SUBSTRUCT(demux_cache_opts, demux_cache_conf)},
{"", OPT_SUBSTRUCT(stream_opts, stream_conf)},

{"", OPT_SUBSTRUCT(ra_ctx_opts, ra_ctx_conf)},
{"", OPT_SUBSTRUCT(gl_video_opts, gl_video_conf)},
{"", OPT_SUBSTRUCT(spirv_opts, spirv_conf)},

#if HAVE_GL
{"", OPT_SUBSTRUCT(opengl_opts, opengl_conf)},
#endif

#if HAVE_VULKAN
{"", OPT_SUBSTRUCT(vulkan_opts, vulkan_conf)},
{"", OPT_SUBSTRUCT(vulkan_display_opts, vulkan_display_conf)},
#endif

#if HAVE_D3D11
{"", OPT_SUBSTRUCT(d3d11_opts, d3d11_conf)},
#if HAVE_D3D_HWACCEL
{"", OPT_SUBSTRUCT(d3d11va_opts, d3d11va_conf)},
#endif
#endif

#if HAVE_EGL_ANGLE_WIN32
{"", OPT_SUBSTRUCT(angle_opts, angle_conf)},
#endif

#if HAVE_GL_COCOA
{"", OPT_SUBSTRUCT(cocoa_opts, cocoa_conf)},
#endif

#if HAVE_COCOA
{"", OPT_SUBSTRUCT(macos_opts, macos_conf)},
#endif

#if HAVE_WAYLAND
{"", OPT_SUBSTRUCT(wayland_opts, wayland_conf)},
#endif

#if HAVE_GL_WIN32
{"opengl-dwmflush", OPT_CHOICE(wingl_dwm_flush,
{"no", -1}, {"auto", 0}, {"windowed", 1}, {"yes", 2})},
#endif

#if HAVE_CUDA_HWACCEL
{"cuda-decode-device", OPT_CHOICE(cuda_device, {"auto", -1}),
M_RANGE(0, INT_MAX)},
#endif

#if HAVE_VAAPI
{"vaapi", OPT_SUBSTRUCT(vaapi_opts, vaapi_conf)},
#endif

{"sws", OPT_SUBSTRUCT(sws_opts, sws_conf)},

#if HAVE_ZIMG
{"zimg", OPT_SUBSTRUCT(zimg_opts, zimg_conf)},
#endif

{"", OPT_SUBSTRUCT(encode_opts, encode_config)},

{"a52drc", OPT_REMOVED("use --ad-lavc-ac3drc=level")},
{"afm", OPT_REMOVED("use --ad=...")},
{"aspect", OPT_REPLACED("video-aspect-override")},
{"ass-bottom-margin", OPT_REMOVED("use --vf=sub=bottom:top")},
{"ass", OPT_REPLACED("sub-ass")},
{"audiofile", OPT_REPLACED("audio-file")},
{"benchmark", OPT_REMOVED("use --untimed (no stats)")},
{"capture", OPT_REMOVED(NULL)},
{"stream-capture", OPT_REMOVED(NULL)},
{"channels", OPT_REMOVED("use --audio-channels (changed semantics)")},
{"cursor-autohide-delay", OPT_REPLACED("cursor-autohide")},
{"delay", OPT_REPLACED("audio-delay")},
{"dumpstream", OPT_REMOVED("use --stream-dump=
};
static const struct MPOpts mp_default_opts = {

.use_terminal = 1,

.msg_color = 1,

.softvol_max = 130,

.softvol_volume = 100,

.softvol_mute = 0,

.gapless_audio = -1,

.wintitle = "​{?media-title:{media-title}}${!media-title:No file} - mpv",

.stop_screensaver = 1,

.cursor_autohide_delay = 1000,

.video_osd = 1,

.osd_level = 1,

.osd_on_seek = 1,

.osd_duration = 1000,

#if HAVE_LUA

.lua_load_osc = 1,

.lua_load_ytdl = 1,

.lua_ytdl_format = NULL,

.lua_ytdl_raw_options = NULL,

.lua_load_stats = 1,

.lua_load_console = 1,

.lua_load_auto_profiles = -1,

#endif

.auto_load_scripts = 1,

.loop_times = 1,

.ordered_chapters = 1,

.chapter_merge_threshold = 100,

.chapter_seek_threshold = 5.0,

.hr_seek = 2,

.hr_seek_framedrop = 1,

.sync_max_video_change = 1,

.sync_max_audio_change = 0.125,

.sync_max_factor = 5,

.load_config = 1,

.position_resume = 1,

.autoload_files = 1,

.demuxer_thread = 1,

.demux_termination_timeout = 0.1,

.hls_bitrate = INT_MAX,

.cache_pause = 1,

.cache_pause_wait = 1.0,

.ab_loop = {MP_NOPTS_VALUE, MP_NOPTS_VALUE},

.ab_loop_count = -1,

.edition_id = -1,

.default_max_pts_correction = -1,

.initial_audio_sync = 1,

.frame_dropping = 1,

.term_osd = 2,

.term_osd_bar_chars = "[-+-]",

.consolecontrols = 1,

.playlist_pos = -1,

.play_frames = -1,

.rebase_start_time = 1,

.keep_open = 0,

.keep_open_pause = 1,

.image_display_duration = 1.0,

.stream_id = { { [STREAM_AUDIO] = -1,

[STREAM_VIDEO] = -1,

[STREAM_SUB] = -1, },

{ [STREAM_AUDIO] = -2,

[STREAM_VIDEO] = -2,

[STREAM_SUB] = -2, }, },

.stream_auto_sel = 1,

.subs_with_matching_audio = 1,

.audio_display = 1,

.audio_output_format = 0,  // AF_FORMAT_UNKNOWN

.playback_speed = 1.,

.pitch_correction = 1,

.sub_auto = 0,

.audiofile_auto = -1,

.coverart_auto = 1,

.osd_bar_visible = 1,

.screenshot_template = "mpv-shot%n",

.play_dir = 1,
.audio_output_channels = {
    .set = 1,
    .auto_safe = 1,
},

.index_mode = 1,

.mf_fps = 1.0,

.display_tags = (char **)(const char*[]){
    "Artist", "Album", "Album_Artist", "Comment", "Composer",
    "Date", "Description", "Genre", "Performer", "Rating",
    "Series", "Title", "Track", "icy-title", "service_name",
    "Uploader", "Channel_URL",
    NULL
},

.cuda_device = -1,

.watch_later_options = (char **)(const char*[]){
    "osd-level",
    "speed",
    "edition",
    "pause",
    "volume",
    "mute",
    "audio-delay",
    "fullscreen",
    "ontop",
    "border",
    "gamma",
    "brightness",
    "contrast",
    "saturation",
    "hue",
    "deinterlace",
    "vf",
    "af",
    "panscan",
    "aid",
    "vid",
    "sid",
    "sub-delay",
    "sub-speed",
    "sub-pos",
    "sub-visibility",
    "sub-scale",
    "sub-use-margins",
    "sub-ass-force-margins",
    "sub-ass-vsfilter-aspect-compat",
    "sub-ass-override",
    "ab-loop-a",
    "ab-loop-b",
    "video-aspect-override",
    NULL
},

};
const struct m_sub_options mp_opt_root = {

.opts = mp_opts,

.size = sizeof(struct MPOpts),

.defaults = &mp_default_opts,

};
#endif /* MPLAYER_CFG_MPLAYER_H */
