[Updated] Test Method for Running Android App with ARChon- Community

[Updated] Test Method for Running Android App with ARChon

Community Discussion 8588 views · 17 replies ·

cxbii

deepin

2016-01-15 23:07

Author

A simple script is provided.
Download and unzip the script

, then grant the executable permission in properties of context menu.
Then execute the following command in terminal:

android.sh xx.apk

Copy the Code

And you can automatically unzip and run the Android program.

Note: You should install ARChon by yourself before using the script, namely execute the following command in terminal:

sudo apt-get install archon-integration deepin-archon -y

Copy the Code

Here is the video tutorial for Running Android App with ARChon in deepin:https://youtu.be/evKCuOJPZHs

=========================================================================================================
Hi all:
Now we announce the test method for running Android App with ARChon. Packaging is not discussed in this post due to its complexity.
Please reply this post with the names and download links of Android Apps which passed tests. We will add them to Deepin Store as soon as possible.

Configuration Environment

1. Install deepn 15 64-bit;
2. Install ARChon, execute in terminal:

sudo apt-get install archon-integration deepin-archon -y

Copy the Code

3. Check if the system supports WebGL by visiting chrome://gpu/, check if WebGL displays Hardware accelerated.

Test Method

1. Download Android apk App for testing, please try to download Pad version;
2. Extract apk App, execute in terminal:

/usr/lib/node_modules/chromeos-apk/chromeos-apk --archon -t --scale --name "Android App" xxx.apk

Copy the Code

##xxx.apk is the apk file name to be extracted.

3. Run test, execute in terminal:

/lastore/framework/myarchon/archonrun --silent-launch --load-and-launch-app=full directory to the extracted apk App

Copy the Code

Test Case
1. Download bukamanhuaHD_17301579.apk;
2. Extract Android apk App, execute in terminal:

/usr/lib/node_modules/chromeos-apk/chromeos-apk --archon -t --scale --name "Android App" bukamanhuaHD_17301579.apk

Copy the Code

3. Run test, execute in terminal:

/lastore/framework/myarchon/archonrun --silent-launch --load-and-launch-app=/home/cxbii/Downloads/cn.ibuka.manga.hd.android

Copy the Code

4. Running Successfully!

Notes:
1. Now only deepin 15 64-bit can run Android Apps, other deepin systems can't.
2. Android Apps can not be used in systems that do not support WebGL.

Reply Like 0 Favorite View the author

All Replies

menny

deepin

2016-01-17 12:38

i don't understand this part:
1. Download Android apk App for testing, please try to download Pad version;
2. Extract apk App, execute in terminal:
/usr/lib/node_modules/chromeos-apk/chromeos-apk --archon -t --scale --name "Android App" xxx.apk ##xxx.apk is the apk file name to be extracted.

cloud you please make a video tuturial? please ,is confused

Reply Like 0 View the author

menny

deepin

2016-01-17 12:44

i don't understand

please make a video tuturial

Reply Like 0 View the author

cxbii

deepin

2016-01-21 23:42

https://bbs.deepin.org/post/30593
i don't understand

please make a video tuturial

The apk file should be in the exact directory. You should move the apk file to chaemel@chemel-pc

Reply Like 0 View the author

raeesiqbal

deepin

2016-02-16 08:24

Does this work on Deepin 15.1 64bit?

Reply Like 0 View the author

giovannigil

deepin

2016-02-28 12:35

He gave error by following this tutorial.
[attach]10308[/attach]

Reply Like 0 View the author

Favaro

deepin

2016-02-28 13:32

Make please a Video turtorial , i dont understand this to ^^

Reply Like 0 View the author

u855697021

deepin

2016-03-08 08:42

Personally I think using ARC Welder instead of ARChon to test APK programs are better idea.
ARC Welder is backed by Google, who knows Android best, while ARChon is a third party project.
Also by using ARC Welder you don't need to operate in terminal, which is a good news for those not familiar with Linux.

Reply Like 0 View the author

austra

deepin

2016-03-12 15:32

Hi,

I have tried following your example. I am new to Linux, please help me get it to work.
This is what i did to install Archon:
I opened Deepin Terminal and executed the followinig command:

sudo apt-get install archon-integration deepin-archon -y

I then checked in my browser to make sure GPU is supported.

I moved the test apk to /usr/lib/node_modules/chromeos-apk folder.

This is what I get when trying to execute the command:
